Μηχάνημα διάσπασης πέτρας KUZIK BR400T

FOR SALE – COMPLETE AUTOMATED KUZIK BR400T NATURAL STONE SPLITTING LINE – 400 TON

WRKB-GRANIT Sp. z o.o. offers for sale a complete, fully integrated KUZIK BR400T production line designed for industrial splitting of natural stone.

The line is intended for the production of building stone, dimensional stone and other natural stone products. It combines material loading and feeding, computer-controlled positioning, hydraulic splitting, material manipulation and product receiving in one integrated technological process.

The complete production line is located in Strzegom, Poland and is available for inspection by appointment.

MAIN TECHNICAL PARAMETERS

• Splitting force: 400 tons / 400,000 kg
• Splitting head length: 1,500 mm
• Maximum material feed height: 500 mm
• Maximum hydraulic pressure of the splitter: 350 bar
• Cylinder stroke: 510 mm
• Number of splitting knives: 52
• Hydraulic oil tank: 390 l
• Pump capacity: 130 l/min
• Main splitter motor power: 11 kW
• Power supply: 400 V / 50 Hz
• Main splitter weight: 10,500 kg
• Computer-controlled and synchronized production process

COMPLETE LINE – 6 INTEGRATED MODULES

1. ROLLER LOADING TABLE

Heavy-duty loading table designed for loading large natural stone slabs using a forklift or loader.

The table is equipped with a hydraulically raised rotating platform and rubber-coated rollers for material transfer.

2. TWO-SPEED FEEDING TABLE ST 4000 × 1200

Industrial feeding table for transporting and positioning heavy stone material.

Technical parameters:
• Working area: 1,200 × 4,000 mm
• Maximum load capacity: 10,000 kg
• Travel speed: 7 m/min
• Motor power: 1.5 kW
• Maximum gearbox output torque: 1,500 Nm
• Gear ratio: 1:100
• Power supply: 400 V / 50 Hz
• Auxiliary hydraulic drive: 100 bar
• Bidirectional material transport

The table also enables large stone slabs and blocks to be rotated during the production process.

3. AUTOMATIC POSITIONING MODULE

The positioning module is controlled by the central computer and is responsible for precise positioning of the stone material according to programmed parameters.

It synchronizes material transport and positioning with the splitting process, increasing production repeatability and reducing manual handling.

The system includes safety equipment such as a light curtain, magnetic safety gates and an operator control panel.

Technical parameters:
• Working area: 1,200 × 3,500 mm
• Maximum load capacity: 10,000 kg
• Travel speed: 7 m/min
• Motor power: 1.5 kW
• Power supply: 400 V / 50 Hz

4. KUZIK BR 1500 × 500 × 400T HYDRAULIC STONE SPLITTER

The central machine of the production line is a heavy-duty hydraulic stone splitter with a maximum splitting force of 400 tons.

The splitting system uses four hydraulic cylinders. The production cycle is controlled and synchronized by the central computer.

Technical parameters:
• Splitting force: 400,000 kg / 400 tons
• Splitting head length: 1,500 mm
• Maximum material height: 500 mm
• Maximum hydraulic pressure: 350 bar
• Cylinder stroke: 510 mm
• Number of splitting knives: 52
• Hydraulic oil tank: 390 l
• Pump capacity: 130 l/min
• Motor power: 11 kW
• Power supply: 400 V / 50 Hz
• Machine weight: 10,500 kg

5. MP-1200 × 500 HYDRAULIC MANIPULATOR

The hydraulic manipulator is designed for rotating, positioning and accurately placing stone material under the splitting knives.

Technical parameters:
• Maximum lifting capacity: 500 kg
• Working reach: 1,800 mm
• Hydraulic working pressure: 100 bar
• Control voltage: 24 V DC
• Manipulator weight: 583 kg

6. RECEIVING TABLE 4000 × 1200

The receiving table handles material after the splitting process.

It is equipped with a hydraulic rotating platform that enables the material to be lifted and rotated.

The system also includes a front hydraulic trapdoor designed for automatic removal of production waste.

Technical parameters:
• Working area: 1,200 × 4,000 mm
• Maximum load capacity: 10,000 kg
• Travel speed: 7 m/min
• Motor power: 1.5 kW
• Power supply: 400 V / 50 Hz

AUTOMATION AND TECHNOLOGY

The KUZIK BR400T offered for sale is not only a single stone splitter. The offer includes the COMPLETE INTEGRATED PRODUCTION LINE.

The system integrates:
• material loading
• material transport
• automatic positioning
• hydraulic splitting
• hydraulic manipulation
• product receiving
• waste removal

The central computer controls and synchronizes the individual stages of the production process.

The technology was developed through cooperation between WRKB-GRANIT Sp. z o.o., KUZIK Sp. z o.o. and Wroclaw University of Environmental and Life Sciences in Poland.

According to the project documentation, the technology provides the following benefits:

• approximately 14–18% lower electricity consumption per unit of production
• approximately 11–16% lower noise during the splitting process
• improved utilization of natural stone raw material
• increased production repeatability
• reduced manual material handling
• improved working conditions

The technology has also been subject to scientific assessment.

SALE INFORMATION

Year of manufacture: 2015
Condition: Used

Price: PLN 1,200,000 NET + VAT

Location:
WRKB-GRANIT Sp. z o.o.
Morawa 37
58-150 Strzegom
POLAND

The complete production line is available for inspection by prior appointment.

A detailed technical and sales catalogue is available for interested buyers.

A VIDEO SHOWING THE KUZIK BR400T PRODUCTION LINE IN OPERATION IS ALSO AVAILABLE.

Additional photographs, technical information and documentation can be provided upon request.

International buyers are welcome.

CONTACT:
WRKB-GRANIT Sp. z o.o.
Phone: προβολή επαφών

Please contact us for further technical information, the full catalogue, the operating video or to arrange an on-site inspection in Poland.
